High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit

Buy Mining Jack Hammers,Dth Air Power Hammer,Low Pressure Dth Hammers Product

$1,300.00

Have chosen: There are no options selected

Start To Order

Add To Cart Successfully!

High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit

High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit

Buy Mining Jack Hammers,Dth Air Power Hammer,Low Pressure Dth Hammers Product

  • Product Code:62439091870
    MOQ30

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Products Description
High quality Low Pressure hammer cir 90 dth Hammer with hammer drill bit
It is a kind of high air pressure DTH hammer without foot valve,and it is our newest design.It is also one of the most advanced DTH hammers in the world. Urban high-rise building construction, high-speed rail, highways, bridges, subway construction, hydropower stations, nuclear power plant construction projects will involve the pile foundation project. With the increasing demand for rock-fill holes in rock formations for these projects, the new Speedmaster series designed specifically for these types of projects is being developed with extensive experience in large diameter boreholes and ultra-deep boreholes Large-aperture down-hole impactor, fully meet the construction requirements of the pile foundation construction rock into the rock.
Product Parameter
It has following advantages: 1.Out of the trouble of foot valve fracture expansion and contraction. 2.Lower energy consumption and higher impact frequency.The drilling speed is 15%-30% higher than the one with foot valve. 3.Simple structure,reliable parts,long life span,easy and cheap maintenance. 4.Lower air and oil consumption.The oil consumption is about 10% lower than the one with foot valve.
Technical Data
Length(Without Bit)
ND580
ND680
ND680S
ND882
ND1080
978mm
1135mm
1359mm
1266mm
1412mm
Weight(Without Bit)
60.00kg
100.50kg
≈200.00kg
180.00kg
288.00kg
External Diameter
Ø126mm
Ø148mm
Ø185mm
Ø185mm
Ø225mm
Hole Range
Ø136-Ø155mm
Ø158-Ø203mm
Ø195-Ø254mm
Ø200-Ø254mm
Ø254-Ø311mm
Connection Thread
API2 3”/8REG
API3 1”/2REG
-
API4 1”/2REG
API4 1”/2REG
(Optional)
(Optional)
(Optional)
(Optional)
Working Pressure
1.5-2.6Mpa
1.5-2.6Mpa
1.7-3.5Mpa
1.7-3.0Mpa
2.2-3.5Mpa
Impact Rate
32HZ at 1.7 Bar
29HZ at 1.7 Bar
-
28HZ at 1.8 Bar
32HZ at 2.4Bar
Recommended Rotation Speed
30-60r/min
25-55r/min
15-30r/min
25-50r/min
25-50r/min
Air Consumption
1.8Mpa: 12.0m³/min
1.8Mpa: 17.0m³/min
2.4Mpa: 31.0m³/min
1.8Mpa: 23.0m³/min
2.4Mpa: 62.0m³/min
Bit Shank
ND580
ND680
DHD380
ND882
ND1080
Packing And Shipping
Recommend Products
Company Profile
Kaishan water well drilling rig is the largest water well drilling rig manufacturer in China. Kaishan water well drilling rig has complete vertical integration of production .Kaishan headquarters is located in Quzhou, Zhejiang Province,China, approximately 356 kilometers southwest of Shanghai, with its second largest manufacturing facility located in Shanghai, China. Kaishan Compressor currently has 3000 employees.
Specialized in Drilling rig and air compressor for many years.Sales Water well drill rig,Blasthole drill rig/quarry rock blasting Drilling equipment.Screw air comressor/Piston air comprssor,air tank for air compressor.jack hammers,hand rock drill.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
Certificate
Exhibition
Customer praise
FAQ
Q1: Are you a manufacturer?A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.Q2: What does your company produce?A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air compressors.Q3: How about your delivery time?A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends on different products.Q4: What methods of payment do you accept?A: We accept T/T, L/C.Q5: Do you offer any deals or discounts?A: Yes, price depends on different quantity, different quantity will give you different price.
Quick Details
ConditionNew
Warranty 6 Months
Applicable Industries Building Material Shops, Farms, Construction works , Energy & Mining
Weight (KG) 48
Showroom Location Turkey, United Kingdom, France, Germany, None
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type New Product 2020
Place of Origin Zhejiang, China
Brand Name Kaishan
Type DTH hammer
Machine Type Drilling Tool
Weight2.5-48kg
Material High quality alloy steel
BrandKaishan
Processing Type Forging
Use Ore Mining
Diameter68--200mm
Product name Dth hammer
Application DTH Drilling
ColorBlack
Key words DTH Hammer
QualityExcellent
Apply To Drill Machine Brand Multiple
Packing Wooden Box
