DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''

Buy Breakout Bench,Dth Hammer Breakout Bench,Dth Tools Automatical Breakout Bench Product

$11,600.00

Have chosen: There are no options selected

Start To Order

Add To Cart Successfully!

DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''
DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''

DTH Tools Automatical Breakout Bench for DTH Hammers from size 3.5'' to 10''

Buy Breakout Bench,Dth Hammer Breakout Bench,Dth Tools Automatical Breakout Bench Product

  • Product Code:62527390081
    MOQ1001

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Products Description
* DTH Hammer Size: 3.5” – 10”
* Bench Size: 1060*930*1050mm
* Weight: 800kg
* Max Tightening Torque: 67 kN*m(50ftlb)
* Max Loosening Torque: 81 kN*m(60ftlb)
* Operating Height: 800mm
* Hydraulic Pressure Range: 0-20 Mpa
* Power: 3Kw, 220V, 50Hz
* Chain Rotation Speed: less than 10 rpm
* Piston Driver Speed: 1.8m per minute

Breakout bench hand hold operation method 1.

1. Put hammer on the bench.
2. Adjust the position of hammer and wrench; use wrench to block the top sub side of hammer; let wrench and jack in the same face.
3. Fix K-shaped base with nut.
4. Fix wrench with nuts.
5. Shake handle of Jack slowly till top sub away from hammer.
6. After top sub dismantled, grease the jack, release nuts, discharge the K-shaped base and turn around the Hammer.
7. Adjust the position of hammer and wrench; use wrench to block the drive chuck of hammer; let wrench and jack in the same face.
8. Fix hammer
9. Fix K-shaped base and the wrench with nut.
10. Shake handle of Jack slowly till drive chuck away from hammer.
Quick Details
ConditionNew
WarrantyUnavailable
Applicable Industries Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining
Local Service Location None
Showroom Location None
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type Ordinary Product
Place of Origin Fujian, China
Brand Name Prodrill
Type Breakout Bench
Machine Type Drilling Tool
Weight800kg
MaterialCarbide
DTH Hammer Size 3.5 -10''
Processing Type Forging
Bench Size 1060*930*1050mm
Use Well Drilling
Max Tightening Torque 67 kN*m(50ftlb)
Max Loosening Torque 81 kN*m(60ftlb)
Power 3Kw, 220V, 50Hz
Hydraulic Pressure Range 0-20 Mpa
Operating Height 800mm
